110 GHz Series
Precision 1.0 mm interface cable assemblies for DC–110 GHz test and measurement. Choose durable TA110 armor, lighter TF110 flexible construction or compact TS110 semi-rigid assemblies.
Choose your cable model
Armored red/black assembly with a 4.00 mm diameter, designed for mechanical durability.
Request DatasheetBare flexible construction, 1.80 mm diameter, designed for low weight and flexibility.
Request DatasheetSemi-rigid precision assembly, 1.19 mm diameter and a 5 mm installation bend radius.
Request DatasheetModel comparison
Electrical performance values reproduced from the 110 GHz series catalogue table. Assembly lengths and connector combinations are listed separately below.
| Parameter | TA110 | TF110 | TS110 |
|---|---|---|---|
| Operating Frequency (GHz) | DC-110 GHz | DC-110 GHz | DC-110 GHz |
| Impedance (Ohm) | 50 | 50 | 50 |
| VSWR — Typical at DC-67 GHz | 1.30 | 1.3 | 1.3 |
| VSWR — Typical at 110 GHz | 1.40 | 1.40 | 1.40 |
| VSWR — Maximum at DC-67 GHz | 1.35 | 1.35 | 1.35 |
| VSWR — Maximum at 110 GHz | 1.45 | 1.45 | 1.45 |
| Typical Mechanical Phase at DC-67 GHz (degree) | ±10 | ±10 | ±10 |
| Typical Mechanical Phase at 110 GHz (degree) | ±12 | ±12 | ±12 |
| Typical Mechanical Amplitude at DC-67 GHz (dB) | ±0.1 | ±0.1 | ±0.1 |
| Typical Mechanical Amplitude at 110 GHz (dB) | ±0.2 | ±0.2 | ±0.2 |
| Velocity Of Propogation (%) | 70 | 70 | 70 |
| Insertion Loss (dB) | 15.81 | 15.81 | 14.48 |
| Shielding Effectiveness (dB) | > 90 | > 90 | > 90 |
110 GHz insertion-loss comparison
These are published insertion-loss values for complete 1.0 mm coaxial cable assemblies at 110 GHz, not cable-only attenuation per 100 m. Individual product designations and specified lengths are provided below.
The TA110 and TF110 traces overlap because the catalogue lists identical insertion-loss values at the three standard lengths.
Choose an assembly
Values are for the specified standard assemblies at 110 GHz; not extrapolated to other lengths or frequencies.
Dimensions and bending limits
| Parameter | TA110 | TF110 | TS110 |
|---|---|---|---|
| Diameter (mm (in)) | 4.00 (0.16) | 1.80 (0.07) | 1.19 (0.05) |
| Minimum Bend Radius — Installation (mm (in)) | 20 (0.8) | 12 (0.5) | 5 (0.2) |
| Minimum Bend Radius — Repeated (mm (in)) | 40 (1.57) | 20 (0.8) | - |
| Nominal Weight (g/m) | 38 | 9 | 6 |
| Temperature Range (°C (° F)) | -55 to +85 (-67 to +185) | -55 to +85 (-67 to +185) | -55 to +85 (-67 to +185) |
Standard 1.0 mm connector configurations
| Connector type | Part-code | Specified frequency | Available cable types |
|---|---|---|---|
| 1.0 mm male | 10M | DC–110 GHz | TA110, TF110, TS110 |
| 1.0 mm female | 10F | DC–110 GHz | TA110, TF110, TS110 |
TA110 — all 9 standard product designations
| Product designation | Cable type | Connector A | Connector B | Length | Frequency | VSWR | Insertion loss |
|---|---|---|---|---|---|---|---|
| TA110-10M10M-00.15M | TA110 | 1.0 mm Male | 1.0 mm Male | 0.15 m | 110 GHz | 1.45 | 3.78 dB |
| TA110-10M10M-00.25M | TA110 | 1.0 mm Male | 1.0 mm Male | 0.25 m | 110 GHz | 1.45 | 5.59 dB |
| TA110-10M10M-00.30M | TA110 | 1.0 mm Male | 1.0 mm Male | 0.30 m | 110 GHz | 1.45 | 6.50 dB |
| TA110-10M10F-00.15M | TA110 | 1.0 mm Male | 1.0 mm Female | 0.15 m | 110 GHz | 1.45 | 3.78 dB |
| TA110-10M10F-00.25M | TA110 | 1.0 mm Male | 1.0 mm Female | 0.25 m | 110 GHz | 1.45 | 5.59 dB |
| TA110-10M10F-00.30M | TA110 | 1.0 mm Male | 1.0 mm Female | 0.30 m | 110 GHz | 1.45 | 6.50 dB |
| TA110-10F10F-00.15M | TA110 | 1.0 mm Female | 1.0 mm Female | 0.15 m | 110 GHz | 1.45 | 3.78 dB |
| TA110-10F10F-00.25M | TA110 | 1.0 mm Female | 1.0 mm Female | 0.25 m | 110 GHz | 1.45 | 5.59 dB |
| TA110-10F10F-00.30M | TA110 | 1.0 mm Female | 1.0 mm Female | 0.30 m | 110 GHz | 1.45 | 6.50 dB |
TF110 — all 9 standard product designations
| Product designation | Cable type | Connector A | Connector B | Length | Frequency | VSWR | Insertion loss |
|---|---|---|---|---|---|---|---|
| TF110-10M10M-00.15M | TF110 | 1.0 mm Male | 1.0 mm Male | 0.15 m | 110 GHz | 1.45 | 3.78 dB |
| TF110-10M10M-00.25M | TF110 | 1.0 mm Male | 1.0 mm Male | 0.25 m | 110 GHz | 1.45 | 5.59 dB |
| TF110-10M10M-00.30M | TF110 | 1.0 mm Male | 1.0 mm Male | 0.30 m | 110 GHz | 1.45 | 6.50 dB |
| TF110-10M10F-00.15M | TF110 | 1.0 mm Male | 1.0 mm Female | 0.15 m | 110 GHz | 1.45 | 3.78 dB |
| TF110-10M10F-00.25M | TF110 | 1.0 mm Male | 1.0 mm Female | 0.25 m | 110 GHz | 1.45 | 5.59 dB |
| TF110-10M10F-00.30M | TF110 | 1.0 mm Male | 1.0 mm Female | 0.30 m | 110 GHz | 1.45 | 6.50 dB |
| TF110-10F10F-00.15M | TF110 | 1.0 mm Female | 1.0 mm Female | 0.15 m | 110 GHz | 1.45 | 3.78 dB |
| TF110-10F10F-00.25M | TF110 | 1.0 mm Female | 1.0 mm Female | 0.25 m | 110 GHz | 1.45 | 5.59 dB |
| TF110-10F10F-00.30M | TF110 | 1.0 mm Female | 1.0 mm Female | 0.30 m | 110 GHz | 1.45 | 6.50 dB |
TS110 — all 9 standard product designations
| Product designation | Cable type | Connector A | Connector B | Length | Frequency | VSWR | Insertion loss |
|---|---|---|---|---|---|---|---|
| TS110-10M10M-00.15M | TS110 | 1.0 mm Male | 1.0 mm Male | 0.15 m | 110 GHz | 1.45 | 3.22 dB |
| TS110-10M10M-00.25M | TS110 | 1.0 mm Male | 1.0 mm Male | 0.25 m | 110 GHz | 1.45 | 4.67 dB |
| TS110-10M10M-00.30M | TS110 | 1.0 mm Male | 1.0 mm Male | 0.30 m | 110 GHz | 1.45 | 5.39 dB |
| TS110-10M10F-00.15M | TS110 | 1.0 mm Male | 1.0 mm Female | 0.15 m | 110 GHz | 1.45 | 3.22 dB |
| TS110-10M10F-00.25M | TS110 | 1.0 mm Male | 1.0 mm Female | 0.25 m | 110 GHz | 1.45 | 4.67 dB |
| TS110-10M10F-00.30M | TS110 | 1.0 mm Male | 1.0 mm Female | 0.30 m | 110 GHz | 1.45 | 5.39 dB |
| TS110-10F10F-00.15M | TS110 | 1.0 mm Female | 1.0 mm Female | 0.15 m | 110 GHz | 1.45 | 3.22 dB |
| TS110-10F10F-00.25M | TS110 | 1.0 mm Female | 1.0 mm Female | 0.25 m | 110 GHz | 1.45 | 4.67 dB |
| TS110-10F10F-00.30M | TS110 | 1.0 mm Female | 1.0 mm Female | 0.30 m | 110 GHz | 1.45 | 5.39 dB |
Where these assemblies are used
High-frequency instrumentation
VNA, millimeter-wave and terahertz research systems.
Device characterization
Semiconductor research, package and IC evaluation.
Flexible or semi-rigid integration
Choose TA110, TF110 or TS110 to balance armor, routing and diameter.
Repeatable precision interconnection
1.0 mm connector options for DC–110 GHz configurations.
Request a Datasheet, Quote or Engineering Sample
Tell us your cable model, application, desired length and connectors. Our RF team will follow up with the relevant information.
