DC-DC power modules
375V Quarter-Brick
Modules
Compact conversion
for high-voltage buses.
An isolated DC-DC family offering nine output-voltage choices in a quarter-brick package. Most variants accept 250–420VDC; the 28V output variants specify a 300–400VDC input range.
Explore specifications ↓
Built around your requirements
Power that fits
your application.
Choose the output rail, current capability and mounting style that match your power architecture. MTT Innovations can discuss your requirements and help assess product selection and customization feasibility.
Isolated conversion
Separate input and output power domains while selecting the voltage and current combination your system requires.
Control & adjustment
TRIM output adjustment, PC remote on/off and CSB current-sharing functions support system-level integration. Confirm interface limits for your model.
Built-in protection
The family includes undervoltage, overvoltage, overcurrent and overtemperature protection. Ask for model-specific thresholds and recovery behavior.
Electrical specifications
Compare module options.
Select the exact ordering model below. On smaller screens, swipe the table horizontally to view all specifications.
| Model | Input (VDC) | Output (VDC ±1%) | Current (A) | Power (W) | Efficiency (%) | Ripple (mV) | Mounting |
|---|---|---|---|---|---|---|---|
| D375C3.3T75BL | 250-420 | 3.3 | 22.5 | 75 | 82 | 118 | Slotted (BL) |
| D375C5T100BL | 250-420 | 5 | 20 | 100 | 82 | 150 | Slotted (BL) |
| D375C8T100BL | 250-420 | 8 | 12.5 | 100 | 84 | 225 | Slotted (BL) |
| D375C12T100BL | 250-420 | 12 | 8.4 | 100 | 85 | 125 | Slotted (BL) |
| D375C15T100BL | 250-420 | 15 | 6.7 | 100 | 85 | 280 | Slotted (BL) |
| D375C24T100BL | 250-420 | 24 | 4.2 | 100 | 85 | 150 | Slotted (BL) |
| D375C28T100BL | 300-400 | 28 | 3.6 | 100 | 85 | 190 | Slotted (BL) |
| D375C36T100BL | 250-420 | 36 | 2.8 | 100 | 85 | 200 | Slotted (BL) |
| D375C48T100BL | 250-420 | 48 | 2.1 | 100 | 85 | 250 | Slotted (BL) |
| D375C3.3T75BL2 | 250-420 | 3.3 | 22.5 | 75 | 82 | 118 | Threaded (BL2) |
| D375C5T100BL2 | 250-420 | 5 | 20 | 100 | 82 | 150 | Threaded (BL2) |
| D375C8T100BL2 | 250-420 | 8 | 12.5 | 100 | 84 | 225 | Threaded (BL2) |
| D375C12T100BL2 | 250-420 | 12 | 8.4 | 100 | 85 | 125 | Threaded (BL2) |
| D375C15T100BL2 | 250-420 | 15 | 6.7 | 100 | 85 | 280 | Threaded (BL2) |
| D375C24T100BL2 | 250-420 | 24 | 4.2 | 100 | 85 | 150 | Threaded (BL2) |
| D375C28T100BL2 | 300-400 | 28 | 3.6 | 100 | 85 | 190 | Threaded (BL2) |
| D375C36T100BL2 | 250-420 | 36 | 2.8 | 100 | 85 | 200 | Threaded (BL2) |
| D375C48T100BL2 | 250-420 | 48 | 2.1 | 100 | 85 | 250 | Threaded (BL2) |
*The 28V output variants specify a 300–400VDC input range; all other listed variants specify 250–420VDC. BL = slotted baseplate; BL2 = threaded baseplate. Ratings depend on the selected model and operating conditions. Confirm thermal requirements, pin assignments and the final drawing before integration.
Design & customization enquiries
Tell us what your
system needs.
Share your technical brief with MTT Innovations. We will help you explore product options and assess whether your requested configuration can be supported.
- 01Input-voltage range, transients and source characteristics
- 02Required output voltage, continuous current and load steps
- 03Available space, mounting method and cooling conditions
- 04Isolation, control interfaces and qualification requirements
