MTT Innovations / RF cable assemblies
MTT3234LFSmall cable.
Versatile connections.
RG316 SMA male to N male.
A flexible 50 Ω assembly for SMA-to-N connections from DC to 1000 MHz.
3D assembly perspective · Select a thumbnail to explore.
Illustrative 500 mm configuration. Connector geometry and routing are approximate.
The assembly
Flexible by construction.
Connected by design.
MTT3234LF combines RG316 coaxial cable with SMA male and N male connectors. A stranded silver-plated copper-clad steel conductor, PTFE dielectric and silver-plated copper braid sit beneath a tan FEP jacket. Specify the assembly length and operating requirements when enquiring.
Stranded core
Silver-plated copper-clad steel with a PTFE dielectric.
RG316 construction
A single silver-plated copper braid and a flexible tan FEP jacket.
SMA male to N male
Gold-plated brass contacts and nickel-plated brass bodies. Between-series connection with standard coupling.
Explore the assembly
Two interfaces. One flexible connection.
Pictures and STEP show an illustrative 500 mm configuration measured along the model centreline including assumed connector lengths. Cable diameter: 2.49 mm; SMA hex: 5/16 inch, as specified. Connector envelopes, internal details and routing are approximate; threads are omitted. The datasheet does not provide a dimensioned assembly drawing. This model is for visualization, not manufacturing, fit verification or mating-interface validation. Ordered length is determined by the selected part configuration.
